Lens Type

2.8 mm to 3.6 mm fixed focal lens

Focal Length & FOV

2.8 mm, horizontal FOV: 107°, vertical FOV: 64°, diagonal FOV: 129°
3.6 mm, horizontal FOV: 83°, vertical FOV: 48°, diagonal FOV: 102°

Lens Mount

M12

Image Settings

Brightness, Sharpness, Smart IR

Frame Rate

TVI: 3K@20 fps, 4 MP@25 fps/30 fps, 1080p@25 fps/30 fps
AHD: 5 MP@20 fps, 4 MP@25 fps/30 fps
CVI: 4 MP@25 fps/30 fps
CVBS: PAL/NTSC

Day/Night Mode

IR/White Light

Wide Dynamic Range(WDR)

Digital WDR

Image Enhancement

Yes

White Balance

Auto/Manual

AGC

Yes

Video Output

Switchable TVI/AHD/CVI/CVBS

Material

Plastic

Dimension

84.6 mm × ⊘85.02 mm (3.33" × ⊘3.35")

Weight

Approx. 160 g (.35 lb.)

Operating Condition

-40° C to 60° C (-40° F to 140° F), Humidity 90% or less (no condensation)

Communication

Hikvision-C

Language

English

Power Supply

12 VDC ± 25% *You are recommended to use one power adapter to supply the power for one camera.

Consumption

Max. 2.9 W

Supplement Light Type

White Light; IR

Supplement Light Range

IR : Up to 20 m
White Light : Up to 20 m
